Electrical Feed-thru Completion Wellhead System
TCX Electrical Feed-thru Completion Wellhead Systems are developed for ESP applications. Penetrator options have been standardized and rationalized to offer flexibility and ease of installation and can fulfill different user's requirements.
W.P.: 2,000psi ~ 5,000 psi
M.C.: AA, BB, CC, DD, EE, FF
T.R.: K~U
PR: PR1, PR2
PSL: PSL1 ~ PSL3
TCX Frac Wellhead Systems are developed to support well fracturing in oil and gas completion processes. As the conventional wellhead's loading capacity is low, and it can't satisfy the request of fracture acidizing, we developed the high pressure fracturing wellhead which allows the direct suspension of tubing. The fracturing string can be direct suspended on the adapter of frac wellhead through the nipple. We can provide a broad range of frac equipments to offer our customers superior flexibility and availability.
W.P.: 10,000psi ~ 15,000psi
M.C.: AA, BB, CC, DD, EE, FF
T.R.: K~U
PR: PR1, PR2
PSL: PSL1 ~ PSL3
Integral Wellhead System is designed to exactly match customer's needs. It can reduce the number of leak paths to the minimum and decrease the weight and size of the overall wellhead system. Making it a preferred solution where there are limiting space or weight concerns.
W.P.: 2,000psi ~ 15,000psi
M.C.: AA, BB, CC, DD, EE, FF, HH
T.R.: K~U
PR: PR1, PR2
PSL: PSL1 ~ PSL3
Choke manifold is a necessary device to control the well kick successfully and execute the pressure control technology on oil/gas well in the course of drilling, as it is, the device is adopted to execute new drilling-well’s technique of balance pressure, which can avoid pollution of oil-layer, improve the speed of drilling and control blowout effectively. One end of the device connects with the side flange of BOP spool. When BOP closes, it can control the finite pressure from casing by adjusting the choke valve’s opening, so balanced drilling can work under minimum pressure-difference.
Size: 1-13/16" ~ 4-1/16"
W.P.: 3,000psi ~ 20,000psi
The drilling mud manifold consists of the mud valve, high pressure spherical union, high pressure core union, tee, high pressure hose, elbow, pressure gauge, and pup joint etc. Ground valve-group adopts gooseneck type tee with compact structure, little fluid resistance and large power effectuality. Adapter spool adopted on rigid valve-group can be directly used as single pipe on site.
Size: 1-13/16" ~ 7-1/16"
W.P.: 2,000psi ~ 15,000psi
In case of increase of the well head pressure, the kill manifold can provide a means of pumping heavy drilling fluid into the well to balance bottom hole pressure so that well kick and blowout can be prevented. In this case, the increasing well head pressure also can be released directly through blowdown lines connected to the kill manifold so as to release bottom hole pressure, or the water and extinguishing agent can be injected into the well using the kill manifold. The check valves on the kill manifold only allow injection of kill fluid or other fluids into the well bore through themselves, but prohibit any backflow so as to perform the kill operation or other operations.
Size: 1-13/16" ~ 4-1/16"
W.P.: 3,000psi ~ 20,000psi
